This machine line automatically cream‑sandwiches round or rectangular biscuits (e.g., Oreo‑type, Marie, cream crackers) and feeds them directly into an on‑edge flow packing machine – without manual transfer. The system includes a touchscreen PLC, Delta servo, Siemens inverters, and Panasonic sensors for reliable, high‑precision operation. Output speed and bagging parameters are fully adjustable.
| Feature | Benefit |
|---|---|
| Adjustable biscuit feeding channel | The channel width can be changed according to biscuit size – no need for extra parts. |
| “No biscuit, no cream” output | Prevents cream waste and keeps the machine clean; each cream pump works only when a biscuit is present. |
| PLC‑controlled biscuit gap setting | Operators can set the desired gap between biscuits on the touchscreen – easy changeover. |
| Double‑jacketed cream tanks | Hot water circulation maintains ideal temperature for cream or jam, even in different climates. |
| Adjustable biscuits feeder | Accommodates various biscuit shapes and sizes quickly. |
| Siemens brand inverter | Ensures stable speed control and energy efficiency for the sandwiching section. |
| Panasonic sensor | High‑precision detection for accurate cream application and counting. |
| One‑color or two‑color cream stencil | Flexible to produce single‑color or dual‑color cream patterns. |
| 4 wheels at the bottom | Machine can be fixed in place or easily moved to another location when needed. |
| Siemens inverter specifically for sandwiching machine | Dedicated drive for sandwiching mechanism – smooth and durable. |
After sandwiching, biscuits are automatically transferred to the on‑edge packing machine, which wraps them upright (tray‑free) for retail presentation.
Packing features:
Date printer included
Photo cell for print registration
Middle plastic brush and belt – guides biscuits smoothly into the packing film
Packing speed: 30–120 bags/min
Bag size range: Length 80–500 mm × Width 60–380 mm × Height 5–45 mm
Max film width: 370 mm
Film materials: OPP / PE / PVC / CPP / PTFE / KOP / aluminum foil
Total power/voltage: 5 kW / Single‑phase 220V AC 50Hz
Machine weight (packer only): 650 kg
The packing machine connects directly to the sandwiching output – no manual feeding required.
| Parameter | Value |
|---|---|
| Output product | Sandwich biscuits (cream, jam, or chocolate) |
| Biscuit shape & size | Rectangle: L 35–70 × W 30–60 mm Round: Φ 35–70 mm |
| Control system | Delta Servo + PLC + touch screen |
| Inverter | Siemens |
| Sensor | Panasonic |
| Cream options | One color or two colors |
| Cream tank design | Double‑jacketed with hot water circulation |
| Mobility | 4 wheels (lockable for fixed operation) |
| Special function | “No biscuit, no cream” – saves cream and reduces cleaning |
